Production capacity: 5–150 t/h
Feeding size: ≤200–≤350 mm
Discharging size: ≤25–≤35 mm
Motor power: 11–480 kw
Total weight: 0.8–37.5 t
Material handling: limestone, coal gangue, bluestone, etc
Hammer crusher is widely used for crushing various materials like stone, granite, trap rock, coke, coal, manganese ore, iron ore, emery, fused aluminum, oxide, fused calcium carbide, lime stone, quarter, alloys and so on.
Hammer crusher can grind, pulverize, and crush a wide range of materials. This crusher employs a rain of hammer blows to shatter and disintegrate the material. Hammer crusher produces a finish product size that is dependent upon openings in perforated screens or grate bars, number, size and type of hammers, grinding plate setting, rotor speed, etc.
1. The crushing ratio ranges from 10 to 25 or even higher to 50.
2. The AMC alloy hammerhead enjoys a service life increased by 50~150%.
3. The theory of stone hitting effectively reduces the wear load of hammerhead and grid plate.
4. The military high strength artillery steel spindle is designed with vacuum duplex which increases the strength by 3-4 times.
| Specification |
Capacity(m³/h) |
Motor Power (kw) |
| PCΦ400×300 |
5-10 |
4P 11KW |
| PCΦ600×400 |
10-22 | 4P 22KW |
| PCΦ800×600 |
18-40 | 6P 55KW |
| PCΦ1000×800 |
25-50 |
8P 75KW |
| PCΦ1000×1000 |
30-55 | 8P 90KW |
Production capacity: 200 t/h
Processing material: river pebbles, quartz
Benefits: top notch technique support, all-round services
Production capacity: 250 t/h
Processing material: marble
Benefits: complete technique support, all-round services
